25.2V 100000mAh Lithium-ion Battery (21700)

25.2V 100000mAh Lithium-ion Battery (21700) - Image 2

25.2V 100000mAh Lithium-ion Battery (21700)

The 25.2V 100Ah lithium battery pack is a high-capacity power solution designed for robots, unmanned marine vehicles and energy storage equipment. Built with advanced 21700 lithium cells, the battery provides stable output, long cycle life and reliable performance for demanding industrial applications.

Product Number: 01DQ0144-01
Nominal voltage: 25.2V
Nominal capacity: 10,000 mah
Battery size: 310*240*140mm (Max)
Charging temperature: 0-45℃
Discharge temperature: -20 to 60 ℃
Application fields: unmanned ships, energy storage devices, robots and other fields

Applications of 25.2V Lithium Battery Pack

The 25.2V 100Ah lithium battery pack is widely used in various intelligent and industrial systems.

Typical applications include:

• Unmanned surface vehicles (USV)
• Industrial robots and automation equipment
• Portable energy storage systems
• Marine electronic equipment
• Intelligent robotic platforms

Key Features

• High capacity 100Ah lithium battery pack
• High performance 21700 lithium battery cells
• Stable 25.2V output for industrial equipment
• Long cycle life and high reliability
• Integrated battery management system (BMS)
• Support for customized lithium battery solutions

Advantages of 21700 Lithium Battery Technology

21700 lithium battery cells provide higher energy density and better thermal performance compared with traditional 18650 cells. This allows lithium battery packs to achieve larger capacity and longer operating time. The 25.2V 100Ah lithium battery pack designed with 21700 cells offers excellent power stability and durability, making it suitable for demanding industrial applications such as robotics, unmanned systems and energy storage devices.

Product Number: 01DQ0144-01
Cell model: 21700/5000mAh/3.6V/50E
Battery specification: 21700/7S20P/100Ah/25.2V
Product size: 310*240*140mm (Max)
Nominal voltage: 25.2V
Nominal capacity: 100Ah
Finished product internal resistance: ≤100mΩ
Charging voltage: 29.4V
Charging current: ≤20A
Discharge current: ≤100A
Discharge cut-off voltage: 19.6V
Battery weight: 13kg
Charging temperature: 0-45℃
Discharge temperature: -20 to 60 ℃
Storage temperature: -20 to 35 ℃
Battery packaging: Blue PVC heat shrink film + epoxy board packaging
Lithium battery protection: short-circuit protection, overcharge protection, over-discharge protection, over-temperature protection, overcurrent protection,ESD protection, etc
Application fields: unmanned ships, energy storage devices, robots and other fields

The blue PVC heat shrink film is encapsulated with epoxy board, which is simple, reliable and easy to install Connector plug output end: XT60 plug output mode is adopted, and the interlocking increases the reliability of electrical conduction. It adopts ultra-soft silicone rubber wire output, which is heat-resistant and enhances the reliability of electrical conductivity Data communication management: 485 communication is adopted for precise data transmission, accurate temperature control, and real-time battery status monitoring and control to eliminate potential safety hazards to the greatest extent BMS communication employs optocoupler isolation. The product supports 485 bus as an optional communication option for customers, supports networking, and has a communication baud rate of 9600bps Battery management: It features high stability, highly accurate monitoring, precise control, ESD protection, and temperature protection functions. Eliminate potential safety hazards to the greatest extent The battery pack is safe and supports 1C rate discharge, with a discharge capacity of over 90%. The battery pack is safe, has good discharge performance and a long cycle life. The battery pack has a high cycle life and conforms to the value concepts of low carbon, energy conservation and environmental protection.
